[tutorial] Flash Global Rom On Bricked, Locked Bl And W/o Edl !


the_maker

DHD Forum Moderator
May 11, 2011
629
82
I know many of you have problems with it, i had it too.
So, i found this thread in MIUI.EN forum from i guy who had a great find in this crazy rom time :)
He managed to find a shortcut with SHIFT that allows the Mi PC Suite (Chinese version) to flash Mi 5 in Recovery Mode (that is the phone with a usb cable on the screen, when you boot it with Volume+ & Power).
I know this is all useless if your Mi 5 is BL unlocked, but its extremely useful for the majority of the users.

All credits go to whatsek !
-----------------------------------

There are many threads with users with the same problem: you can`t flash in recovery because of you locked bootloader, EDL is not working anymore, and the English PC suite is too old. So I downloaded the chinese version of PC Suite:

http://******.d.miui.com/MiFlash/MiInst.exe

1. You will need d the full OTA ROM of your choice (chinese or global, Beta or Stable) http://en.miui.com/download-299.html
Save it on a location where you can find it again.

2. Boot Mi 5 in recovery: (Press and hold Power and Volume+, until Mi logo appears, release the buttons and a picture of a phone with cable appears)

3. Connect it to the computer, and with the THE SHIFT KEY PRESSED! click on this icon:
http://imgur.com/riGFBtd

4. Browse to the rom file you downloaded, and select it. (When it confirms, click the middle button to begin flashing). It will take up to 45 minutes: http://imgur.com/GsBUy2h
It boots normal in the end automatically: http://imgur.com/sG4bENR

Original thread: http://en.miui.com/thread-291785-1-1.html

Apr 30, 2016
13
13
I know many of you have problems with it, i had it too.
So, i found this thread in MIUI.EN forum from i guy who had a great find in this crazy rom time :)
He managed to find a shortcut with SHIFT that allows the Mi PC Suite (Chinese version) to flash Mi 5 in Recovery Mode (that is the phone with a usb cable on the screen, when you boot it with Volume+ & Power).
I know this is all useless if your Mi 5 is BL unlocked, but its extremely useful for the majority of the users.

All credits go to whatsek !
-----------------------------------

There are many threads with users with the same problem: you can`t flash in recovery because of you locked bootloader, EDL is not working anymore, and the English PC suite is too old. So I downloaded the chinese version of PC Suite:

http://******.d.miui.com/MiFlash/MiInst.exe

1. You will need d the full OTA ROM of your choice (chinese or global, Beta or Stable) http://en.miui.com/download-299.html
Save it on a location where you can find it again.

2. Boot Mi 5 in recovery: (Press and hold Power and Volume+, until Mi logo appears, release the buttons and a picture of a phone with cable appears)

3. Connect it to the computer, and with the THE SHIFT KEY PRESSED! click on this icon:
http://imgur.com/riGFBtd

4. Browse to the rom file you downloaded, and select it. (When it confirms, click the middle button to begin flashing). It will take up to 45 minutes: http://imgur.com/GsBUy2h
It boots normal in the end automatically: http://imgur.com/sG4bENR

Original thread: http://en.miui.com/thread-291785-1-1.html

need activate usb debug previously?


21071992

Members
Mar 3, 2013
17
15
thanks very much, it's an easy method and less complicated than other methods, thanks again :D


the_maker

DHD Forum Moderator
May 11, 2011
629
82
This is the ONLY method since all options got locked by Xiaomi :)

Sent from Mi 5 ќутук црн


Jure24

Members
Jun 14, 2016
15
15
Hello, i have MI 5 bought form *******, and with this method i cant access to recovery mode. :(


the_maker

DHD Forum Moderator
May 11, 2011
629
82
Hello, i have MI 5 bought form *******, and with this method i cant access to recovery mode. :(
Just hold Volume+ and Power.. This is basic phone function, has nothing to do with the seller or the Rom..

Sent from Mi 5 ќутук црн


the_maker

DHD Forum Moderator
May 11, 2011
629
82
Hmmm... Very strange.. Its the phone original?

Sent from Mi 5 ќутук црн


the_maker

DHD Forum Moderator
May 11, 2011
629
82
They can not overwrite the Recovery, it must be there. And if its not, then your phone its bricked and it wont turn on.. If it turns on, then it must be there 100%.. Hold the both buttons while it shows the Mi logo, then release the Power and hold only V+ for few seconds more, it will show a phone with usb cable..

Sent from Mi 5 ќутук црн


the_maker

DHD Forum Moderator
May 11, 2011
629
82
Install Mi Flas and it will install most of the drivers.. If it doesnt again, restart Windows in Advanced Mode and start it with Disabled Driver Signature. Then, install them again, and it should recognise it as Mi 5.

Sent from Mi 5 ќутук црн


Jure24

Members
Jun 14, 2016
15
15
Phone works normal on miui 7.2.13.0 multilanguige, but just cannot access to recovery mode. Guess i have to wait for unlock code :)

  • Like
Reactions: the_maker

the_maker

DHD Forum Moderator
May 11, 2011
629
82
Phone works normal on miui 7.2.13.0 multilanguige, but just cannot access to recovery mode. Guess i have to wait for unlock code :)
Man i dont know why you can not enter Recovery, its simply unbelievable :)
Ok, wait for unlock..

Sent from Mi 5 ќутук црн
